Sensor type | Electrochemical from reputable British manufacturer |
Measurement range | 0.00 – 2.00 ‰ |
Measurement units | ‰ (permille), mg/L (BrAC), mg/100 ml (BAC) * Possibility to change the measuring unit by the service. Factory setting: ‰ |
Accuracy of indications | At the standard concentration 0.04% BAC: Blowing distance 3cm: ±0.05‰ Blowing distance 6cm: ±0.06‰ Blowing distance 10cm: ±0.10‰ |
Alarm threshold | 0.00, 0.20, 0.50, 0.80‰ * Possibility to change the threshold setting by the service. Factory setting: 0.2‰ |
Time to prepare for work | ± 5 seconds * Time to prepare the device for the first measurement. |
Sampling time | ± 8 seconds * Possibility to change the threshold setting by the service in the range of 3 ~ 15 sec. |
Sample analysis time | 1 ~ 15 seconds |
Time between consecutive measurements | 15 ~ 45 sec, depending on alcohol concentration in previous measurement |
Measurement modes | Fast - distance measurement, without the use of a mouthpiece |
Sampling mode | Automatic Manual |
Memory | 8000 measurement records |
Cooperation with application | No |
Cooperation with printer | No |
Display | 1.3” TFT LCD color display |
Additional features | 3-stage torch (top, bottom, top and bottom) Red beacon (steady or flashing) |
Housing | ABS, color black |
Usage | Big companies, medium and small companies, personal use, screening, police |
Additionally included | Cover Hand strap USB adapter Micro USB cable User manual Warranty card |
Power | |
Power source | 1500 mAh, built-in battery DC 3.7V |
Battery life | ± 6 hours, more than 4,000 tests |
Energy saving | Automatic power off after 5 minutes |
Battery discharge indication | Yes |
Working and storage conditions | |
Working conditions | Temperature: -5 ~ 50°C Humidity: up to 95% RH Ambient pressure: 600 – 1400 hPa |
Storage conditions | Temperature: -30 ~ 70°C Humidity: 20 ~ 98% RH Ambient pressure: 600 – 1400 hPa |
Quality and safety | |
Certificates and approvals | CE mark, TÜV Nord: ISO 9001 |
Recommended calibration | Every 6 - 12 months |
Free calibration | No |
Warranty | 1 year |
